製品一覧
BLE搭載MCU一覧
| Apollo3 Blue |
Apollo3 Blue Plus |
Apollo4 Blue |
|
|---|---|---|---|
| MCU Frequency |
48MHz/96MHz | 48MHz/96MHz | 96MHz/192MHz |
| MCU | 32-bit ARM Cortex-M4F |
32-bit ARM Cortex-M4F |
32-bit ARM Cortex-M4F |
| MCU Power Efficiency |
6uA/MHz | 6uA/MHz | 4uA/MHz |
| NVM | 1MB Flash | 2MB Flash | 2MB MRAM |
| SRAM | 384KB | 768KB | 1.8MB |
| Voltage | 1.8 - 3.6V | 1.8 - 3.6V | 1.71 - 2.2V |
| ADC | 14 bit, 15-channel, up to 2.67 MSps |
14 bit, 15-channel, up to 2.67 MSps |
12 bit, 11-channel, up to 2.8 MSps |
| UART | 2 | 2 | 4 |
| I/O | I×C /SPI masters (6x) I×C /SPI slave |
I×C /SPI masters (6x) I×C /SPI slave |
I×C /SPI masters (7x) I×C /SPI slave USB FS/HS SDIO v3.0/1x eMMC |
| MSPI | Dual/Quad/Octal-SPI Master 48MHz SDR |
Dual/Quad/Octal-SPI Master(3x) 48MHz SDR |
Dual/Quad/Octal-SPI Master(3x) 96MHz SDR 48MHz DDR |
| I×S | I×S slave for PDM Audio pass-through |
I×S slave for PDM Audio pass-through |
I×S master/slave(3x) Full-duplex with ASRC |
| Audio | PDM | PDM | 4xStereo PDM Stereo LP AMIC |
| Display | SPI/QSPI | SPI/QSPI | SPI/QSPI MIPI DSIx2 4-layer Display Controller |
| Graphics | - | - | 2D/2.5D GPU |
| Security | Secure SPOT | Secure SPOT | Secure SPOT 2.0 |
| Connectivity | BLE5.0* | BLE5.0* | BLE5.1 |
| RF Sensitivity | -94dBm | -94dBm | -97dBm |
| Rx current | 3mA | 3mA | 3mA |
| Tx current | 3mA @ 0dBm | 3mA @ 0dBm | 3mA @ 0dBm |
| Tx Output Power |
-20 dBm to +4dBm | -20 dBm to +4dBm | -20 dBm to +6.8dBm |
| Packages (mm) |
WLCSP: : 3.37 x 3.25 x 0.45 0.35 pitch, 66-pin 37GPIO |
BGA: 5.3 x 4.3 x 0.8 0.4 pitch, 108-pin, 74GPIO |
BGA: 4.7 x 4.7 x 0.9 0.35 pitch, 131-pin, 81 GPIO |
| WLCSP(Thin): 3.37 x 3.25 x 0.3 0.35 pitch, 66-pin 37GPIO With backside coating |
|||
| BGA: 4.5 x 4.5 x 0.8, 0.5 pitch, 81-pin, 50GPIO |
汎用MCU一覧
| Apollo | Apollo2 | Apollo3 | Apollo4 | |
|---|---|---|---|---|
| MCU Frequency |
24MHz | 48MHz | 48MHz/96MHz | 96MHz/192MHz |
| MCU | 32-bit ARM Cortex-M4F |
32-bit ARM Cortex-M4F |
32-bit ARM Cortex-M4F |
32-bit ARM Cortex-M4F |
| MCU Power Efficiency |
35uA/MHz | 10uA/MHz | 6uA/MHz | 4uA/MHz |
| NVM | 512KB Flash | 1MB Flash | 1MB Flash | 2MB Flash |
| SRAM | 64KB | 256KB | 384KB | 1.8MB |
| Voltage | 2.2 - 3.8V | 1.8 - 3.6V | 1.8 - 3.6V | 1.71 - 2.2V |
| ADC | 10bit, 13-channel, up to 800kSps |
14bit, 15-channel, up to 2.67MSps |
14bit, 15-channel, up to 2.67MSps |
12bit, 11-channel, up to 2.8MSps |
| UART | 1 | 2 | 2 | 4 |
| I/O | I²C/SPI master I²C/SPI slave |
I²C/SPI master(6x) I²C/SPI slave |
I²C/SPI master(6x) I²C/SPI slave |
I²C/SPI master(8x) I²C/SPI slave USB FS/HS SDIO v3.0/1x eMMC |
| MSPI | - | - | Dual/Quad/Octal-SPI Master 48MHz SDR |
Dual/Quad/Octal-SPI Master(3x) 96MHz SDR 48MHz DDR |
| I²S | - | I²S slave for PDM Audio pass-through |
I²S slave for PDM Audio pass-through |
I²S master/slave(3x) Full-duplex with ASRC |
| Audio | - | PDM | PDM | 4xStereo PDM Stereo LP AMIC |
| Display | - | - | SPI/QSPI | SPI/QSPI MIPI DSIx2 4-layer Display Controller |
| Graphics | - | - | - | 2D/2.5D GPU |
| Security | - | - | Secure SPOT | Secure SPOT 2.0 |
| Connectivity | - | - | - | - |
| RF Sensitivity |
- | - | - | - |
| Rx current | - | - | - | - |
| Tx current | - | - | - | - |
| Tx Output Power |
- | - | - | - |
| Packages | WLCSP: 2.49 x 2.90 x 0.5, 0.4 pitch, 41-pin, 27GPIO |
WLCSP: 2.5 x 2.5 X 0.45, 0.35 pitch, 49-pin, 34GPIO |
WLCSP: 3.37 x 3.25 x 0.45, 0.35 pitch, 66-pin, 37GPIO |
WLCSP: 3.9 x 3.9, 121-pin, 82GPIO |
| WLCSP(Thin): 2.5 x 2.5 X 0.3, 0.35 pitch, 49-pin, 34GPIO With backside coating |
||||
| BGA: 5 x 5 x 0.8, 0.35pitch, 146-pin, 105GPIO |
||||
| BGA: 4.5 x 4.5 x 0.8 0.5 pitch, 64-pin, 50GPIO |
BGA: 4.5 x 4.5 x 0.8 0.5 pitch, 64-pin, 50GPIO |
RTC製品一覧
| Part Number | AM1805AQ | AM1815AQ | AM0805AQ | AM0815AQ |
|---|---|---|---|---|
| Interface | I²C | SPI | I²C | SPI |
| SRAM (byte) |
256 | 256 | 256 | 256 |
| Power Switch | ○ | ○ | － | － |
| Package | 16-Pin QFN | 16-Pin QFN | 16-Pin QFN | 16-Pin QFN |
| PKG size | 3mm × 3mm | 3mm × 3mm | 3mm × 3mm | 3mm × 3mm |
