Bluetooth® Modules（Former Products）

本製品のDataReport関連の資料につきましては、無線モジュールのお問合せ先までご連絡お願いいたします。

RAM Flash

標準

10.0 x 15.4 x 2.0 mm

中型

9.6 x 12.9 x 2.0 (1.3) mm

小型

5.1 x 11.3 x 1.3 mm

超小型

3.25 x 8.55 x 1.00 (0.85) mm
nRF5340 512KB
for App.
64KB
for Network 		1MB
for App.
256KB
for Network
nRF52840 256KB 1MB EYSKBNZWB EYSKDNZWB EYSKJNZWB
      EYSKBNUWB-VX   EYSKJNAWB-VX
nRF52833 128KB 512KB EYSPBNZUA EYSPDNZUA EYSPJNZUA
nRF52832 64KB 512KB   EYSHCNZWZ EYSHJNZWZ EYSHSNZWZ
nRF52820 32KB 256KB   EYSRCNZUY   EYSRSNZUY
nRF52811 24KB 192KB   EYSNCNZWW   EYSNSNZWW
nRF52810 24KB 192KB   EYSLCNZWW   EYSLSNZWW
Application Embedded

ソフト非内蔵

Bluetooth® low energy (BLE) Basic Module

Part Number Feature Dimension
(mm) 		Bluetooth ®
Ver. 		Chip Set Soft
device 		RAM Flash I/F CPU Crystal Operaion
Temp.(℃) 		ANT
support 		Certification Sensing Evaluate
Solution 		Evaluation
Board 		Evaluation
Kit 		Overview Data
Report

EYSKBNZWB
(Not Recommended for New Design)

High-end 10.0x15.4x2.0 v5.0 nRF52840 S140
V6.1.0 		256KB 1MB USB
UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz
32.768kHz 		-40 to +85 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSKBNZWB EKSKBNZWB V4.4 V1.1

EYSKDNZWB
(Not Recommended for New Design)

High
Performance
Antenna 		9.6x12.9x1.3 v5.0 nRF52840 S140
V6.1.0 		256KB 1MB USB
UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz -40 to +85 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSKDNZWB EKSKDNZWB V4.4 V1.0

EYSKJNZWB
(Not Recommended for New Design)

High-end 5.1x11.3x1.3 v5.0 nRF52840 S140
V6.1.0 		256KB 1MB UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz -40 to +85 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		EY1SENSOR-SKT EBSKJNZWB EKSKJNZWB V4.4 V1.1

EYSPBNZUA
(Not Recommended for New Design)

Low cost 10x15.4x2.0 v5.2 nRF52833 S140
V7.0.1 		128kB 512kB USB
UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz
32.768kHz 		-40 to +105 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSPBNZUA EKSPBNZUA V4.4 V1.0

EYSPDNZUA
(Not Recommended for New Design)

Low cost 9.6x12.9x1.3 v5.3 nRF52833 S140
V7.2.0 		128kB 512kB USB
UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz
32.768kHz 		-40 to +105 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSPDNZUA EKSPDNZUA - -

EYSPJNZUA
(Not Recommended for New Design)

Low cost 5.1x11.3x1.3 v5.3 nRF52833 S140
V7.2.0 		128kB 512kB UART
SPI
I2C
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz
32.768kHz 		-40 to +105 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSPJNZUA EKSPJNZUA - -

EYSHCNZWZ
(Not Recommended for New Design)

High
Performance 		9.6x12.9x2.0 v5.0 nRF52832 S132
V5.0.0 		64KB 512KB UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz
32.768kHz 		-40 to +85 * Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		EY1SENSOR-SKT EBSHCNZWZ EKSHCNZWZ V4.4 V1.5

EYSHJNZWZ
(Not Recommended for New Design)

High
Performance 		5.1x11.3x1.3 v5.0 nRF52832 S132
V5.0.0 		64KB 512KB UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz -40 to +85 * Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		EY1SENSOR-SKT EBSHJNZWZ EKSHJNZWZ V4.4 V1.6

EYSHSNZWZ
(Not Recommended for New Design)

High
Performance 		3.25x8.55x0.85 v5.0 nRF52832 S132
V5.0.0 		64KB 512KB UART
SPI
I2C
I2S
PDM
NFC-A 		ARM
Cortex
M4F 		32MHz -40 to +85 * Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		EY1SENSOR-SKT EBSHSNZWZ EKSHSNZWZ V4.4 V1.6

EYSRCNZUY
(Not Recommended for New Design)

Low cost 9.6x12.9x2.0 v5.3 nRF52820 S140
V7.2.0 		32KB 256KB USB
UART
SPI
I2C 		ARM
Cortex
M4 		32MHz
32.768kHz 		-40 to +105 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSRCNZUY EKSRCNZUY V4.4 V1.0

EYSRSNZUY
(Not Recommended for New Design)

Low cost 3.25x8.55x1.00 v5.3 nRF52820 S140
V7.2.0 		32KB 256KB USB
UART
SPI
I2C 		ARM
Cortex
M4 		32MHz -40 to +105 # Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSRSNZUY EKSRSNZUY V4.4 V1.0

EYSNCNZWW
(Not Recommended for New Design)

Low cost 9.6x12.9x2.0 v5.2 nRF52811 S113
V7.0.1 		24KB 192KB UART
SPI
I2C
PDM 		ARM
Cortex
M4 		32MHz
32.768kHz 		-40 to +85 * Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		EY1SENSOR-SKT EBSNCNZWW EKSNCNZWW V4.4 V1.0

EYSNSNZWW
(Not Recommended for New Design)

Low cost 3.25x8.55x1.00 v5.2 nRF52811 S113
V7.0.1 		24KB 192KB UART
SPI
I2C
PDM 		ARM
Cortex
M4 		32MHz -40 to +85 * Japan
U.S.A.
Canada
(CE)
BluetoothR
Logo 		EY1SENSOR-SKT EBSNSNZWW EKSNSNZWW V4.4 V1.1

EYSLCNZWW
(Not Recommended for New Design)

Low cost 9.6x12.9x2.0 v5.0 nRF52810 S112
V5.1.0 		24KB 192KB UART
SPI
I2C
PDM 		ARM
Cortex
M4 		32MHz
32.768kHz 		-40 to +85 * Japan
U.S.A.
Canada
(CE)
BluetoothR
Logo 		EY1SENSOR-SKT EBSLCNZWW EKSLCNZWW V4.4 V1.2

EYSLSNZWW
(Not Recommended for New Design)

Low cost 3.25x8.55x1.00 v5.0 nRF52810 S112
V5.1.0 		24KB 192KB UART
SPI
I2C
PDM 		ARM
Cortex
M4 		32MHz -40 to +85 * Japan
U.S.A.
Canada
(CE)
BluetoothR
Logo 		EY1SENSOR-SKT EBSLSNZWW EKSLSNZWW V4.4 V1.0

EYSGCNZWY
(Not Recommended for New Design)

Simple 9.6x12.9x2.0 v4.2 nRF51822 S120
V2.1.0 		32KB 256KB UART
SPI I2C 		ARM
Cortex
M0 		32MHz
32.768kHz 		-25 to +85 - Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSGCNZWY EKSGCNZWY V4.4 V1.9

EYSGCNZXX
(Not Recommended for New Design)

Simple 9.6x12.9x2.0 v4.2 nRF51822 S110
V8.0.0 		16KB 256KB UART
SPI
I2C 		ARM
Cortex
M0 		32MHz
32.768kHz 		-40 to +85 - Japan
U.S.A.
Canada
(CE)
BluetoothR
Logo 		- EBSGCNZWY EKSGCNZWY V4.4 V1.9

EYSGJNZWY
(Not Recommended for New Design)

Simple 5.1x11.3x1.3 v4.2 nRF51822 S120
V2.1.0 		32KB 256KB UART
SPI
I2C 		ARM
Cortex
M0 		32MHz -25 to +85 - Japan
U.S.A.
Canada
(CE)
BluetoothR
Logo 		- EBSGJNZWY EKSGJNZWY V4.4 V2.0

EYSGJNZXX
(Not Recommended for New Design)

Simple 5.1x11.3x1.3 v4.2 nRF51822 S110
V8.0.0 		16KB 256KB UART
SPI I2C 		ARM
Cortex
M0 		32MHz -40 to +85 - Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		- EBSGJNZWY EKSGJNZWY V4.4 V2.0

EYAGJNZXX
(Not Recommended for New Design)

Simple 5.1x11.3x1.3 v4.2 nRF51422 S310
V3.0.0 		32KB 256KB UART
SPI
I2C 		ARM
Cortex
M0 		32MHz -25 to +85 ** Japan
U.S.A.
Canada
(CE)
BluetoothR
Logo 		- EBAGJNZXX EKAGJNZXX V4.4 V2.0

# Supported by S340 Softdevice
* Supported by S212 or S332 Softdevice
** Supported by default Softdevice

ソフト内蔵

Bluetooth® low energy (BLE) Application Embedded Module

Part Number Feature Dimension
(mm) 		Bluetooth® Ver. Chip Set Soft device Application I/F CPU Crystal DCDC Operaion
Temp.(℃) 		Certification Evaluation Board Overview Data Report

EYSKBNUWB-VX
(Not Recommended for New Design)

Application
Embedded 		10.0x15.4x2.0 v5.0 nRF52840 S140
V6.1.0 		Embedded
TY's Application		 USB
UART
SPI		 ARM
Cortex
M4F		 32MHz
32.768kHz		 Supported
with
Internal LC		 -40 to +85 Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo		 EBSKBNUWB-VX V4.4 V1.0

EYSKJNAWB-VX
(Not Recommended for New Design)

 Application
Embedded		 5.1x11.3x1.3 v5.0 nRF52840 S140
V6.1.0		 Embedded
TY's Application 		UART ARM
Cortex
M4F 		32MHz Supported
with
External LC 		-40 to +85 Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		EBSKJNAWB-VX V4.4 V1.0

EYSGCNAWY-VX
(Not Recommended for New Design)

Application
Embedded 		9.6x12.9x2.0 v4.2 nRF51822 S130
V2.0.1 		Embedded
TY's Application		 UART ARM
Cortex
M0		 32MHz
32.768kHz		 Suppoted
with
Internal LC		 -25 to +85 Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo		 EBSGCNAWY-VX V4.4 V1.2

EYSGJNAWY-VX
(Not Recommended for New Design)

 Application
Embedded		 5.1x11.3x1.3 v4.2 nRF51822 S130
V2.0.1		 Embedded
TY's Application 		UART ARM
Cortex
M0 		32MHz Suppoted
with
External LC 		-25 to +85 Japan
U.S.A.
Canada
(CE)
Bluetooth®
Logo 		EYSGJNAWY-VX V4.4 V1.2
